New DAF XB 260 FA hook lift truck

NEW KING HZ-8R hooklift

Basic data:
⦁ Nominal loading capacity – 8000 kg
⦁ Hook height H = 1200 mm (or 900/1000)
⦁ Telescopic main arm
⦁ Net weight – 1100 kg
⦁ Working pressure – 30 MPa
⦁ Length – 3720 mm
⦁ Usable container length 2600-3600 mm and longer

Equipment:
⦁ Hooklift frame made of high-quality steel with laser-cut holes
⦁ Rollers ensure stable container movement
⦁ Controls in the cabin and from outside the vehicle – manual emergency
⦁ Shot-blasted steel structure, then painted with an epoxy primer and topcoated with polyurethane paint in the RAL color scheme.

⦁ Hydraulic container locking system
⦁ Hydraulic oil tank with oil level indicator
⦁ Hydraulic pump
⦁ Side underride guards, side work platforms, aluminum lamp covers
⦁ Hook with automatic latch
⦁ Hook extension slide plates made of high-strength PA6.GSO plastic
⦁ UDT procedure completed

• Day Cab with steel bumper, tinted glass, and electrically operated side windows. Electrically heated main and wide-angle mirrors. Cab width 2130 mm.
• Reinforced mechanical cab suspension.
• Transparent, external green sun visor above the windshield.
• Dual-reflector halogen headlights with impact-resistant Lexan lenses.
• Right-hand drive headlights.
• Daytime running lights. • Bumper-mounted light cluster combined with fog lights and cornering lights.
• Single rear window.
• Green tinted glass.
• Main mirror and wide-angle mirror on the driver's and co-driver's sides. Curbside mirror on the co-driver's side.
• Electric main mirror adjustment.
• Mirror brackets for body widths of 2.10 - 2.29 m.
• Front mirror meets the requirements of Directive 2003/97/EC regarding the forward field of vision.
• Reversing camera, supplied with an additional 5 m cable for replacement around the chassis in the cab. Instructions on where to position the reversing camera can be found in the bodybuilder's guidelines.
• Central door locking with exterior light control. Includes 2 remotes and 2 transponder keys. • Cab color: E1980WHTE
• Headlight and bumper panel color: Stone Grey.
• Cab steps and wind deflector in Stone Grey.
• Chassis color: Gray.
• Left-hand drive.
• Black steering wheel with soft-touch fabric.
• Tilt and height-adjustable steering column with air-operated lock.
• Deluxe driver's seat with air suspension, adjustable damping, and air lumbar support. Seat heating. Integrated headrest. Three-point seat belt. Velour seat upholstery.
• Armrest on the driver's seat.
• Rigid co-driver's seat with integrated headrest and three-point seat belt. Velour seat upholstery with vinyl backing.
• Adjustable armrest on the inside of the passenger seat.
• Black seat belts.
• Storage compartment in the engine compartment.
• Manually controlled air conditioning with air recirculation.
• Roof vent, manual control.
• Power windows.
• 24V to 12V converter, 15A, 180W.
• ECAS remote control with illuminated buttons for various functions, including four memory buttons for programming fixed chassis heights.
• Universal Fleet Management System (FMS) connector with wiring for reading information according to the FMS standard specified by truck manufacturers.
• 10-year PACCAR Connect subscription. PACCAR Connect is an online fleet management system that provides access to relevant truck, driver, and location information. • Digital (smart) VDO DTCO tachograph with a Galileo GNSS receiver, OS-NMA service declaration, and a dedicated short-range communication (DSRC) module, compliant with EU Mobility Package 1 as described in the EU tachograph regulations.
• Speed ​​limiter setting for cruise control/accelerator pedal: 85 km/h.
• DAF Infotainment System: Integrated FM/DAB/DAB+ radio with USB and Bluetooth streaming. Audio system information displayed on the digital instrument panel. Controls on the right spoke of the steering wheel. A separate infotainment display is not included in the option. The Basic speaker system includes three speakers: two subwoofers in the door panels (one in each door) and a full-range speaker in the center of the dashboard.
• Combination antenna - AM/FM, GSM, and GPS. GSM bands 900 MHz, 1800 MHz
